Description

MPPL-MS2 POCSAG Message programmable long transmission range movement sensor

✓ Quick and easy to install versatile movement sensing wireless PIR alarm solution
✓ Compatible with Medpage radio pagers and POCSAG digital message pagers
✓ Selectable radio transmission type; POCSAG long range or MPPL standard range
✓ Suitable for single PIR sensor to pager or multiple sensor applications

The MPPL-MS2 is a new addition to the Medpage range of wireless alarm solutions. Infrared movement sensing technology combined with intelligent operating software, and selectable radio transmission modes make the MPPL-MS2 a versatile security option. The PIR is compatible with all Medpage radio receiver and radio paging devices. Free downloadable PIR setup software is available for PC to enable operating modes, message programming, pager Cap Codes, and radio address IDs to be easily programmed.
The MPPL-MS2, when in long range mode can transmit alarm signals up to and beyond 400 Metres, making it suitable for larger buildings and applications such as Care Homes, Leisure Centres, Agricultural building security, and DIY quick install zonal ID security.

Included items: 1 x PIR motion sensor, 2 x AA batteries, Velcro dots, wall fixing angle adjustable bracket, user guide.

Applications for the MPPL-MS2

Senior wander detection
Patent bed leaving detection
Outbuilding security
Large properties
Stone built properties
Farmyard buildings, barns, stores etc
Quick install zonal alarm systems

Radio frequency transmission type MPPL (100-150M range)

MPPL2 pager
TUMPAG31 pager (3-channel)
PAG-11 pager (9-channel)
NMDRX portable alarm (5-channel)

Radio frequency transmission type POCSAG digital long-range (200-450M)

EM300 digital message pager
EM400 digital message pager
MPPA3 digital message pager watch
MP-900 internet Smartphone hub

Key Features

Quick install PIR movement detection alarm
Simplified installation, one PIR for standard and long-range applications
For domestic, professional care, agricultural, and general secondary security
Free downloadable programming software
Message programmable PIR sensor transmitter
Removeable wall fixing bracket
Indoor PIR movement detection security transmitter
Supplied with wall mount bracket & Velcro fixing tape
Status LED for power/transmission/signal
Compatible with EM300 & EM400 pagers
Compatible with MP-900 internet hub
Supplied with standard message PIR ALARM and configured to standard digital pager radio address code.

Technical Features MPPL-MS2
Radio frequency: 433MHz
Low standby power consumption
Side power on/off switch
Tamper/switch off alert transmission
Trigger range sensitivity adjustment
Selectable re-trigger delay: 5 or 30 seconds
USB programming port socket: Micro USB
Long range transmission - 400M+
Dimensions: 107 x 59 x 39mm
Weight: 40g
Power: 2 x AA batteries
Typical battery life 6-9 months (6-8 opps P/D)
Low battery warning LED
Programming by USB lead with PC software
